My Waveforms (page 2/8)

2011 GMC TERRAIN 2.4 CKP-CKP INT-CMP EXH-CYL 1 AFTER REPAIr

2011 GMC TERRAIN 2.4 CKP-CKP INT-CMP EXH-CYL 1 AFTER REPAIr

Cloud ID : 10421
Vehicle : GMC TERRAIN (2011)
Engine : Gasoline, 4 cylinders (1-3-4-2)
Engine Code : LAF
Note : 2011 GMC TERRAIN 2.4 AFTER TIMING CHAIN REPLACED 1 CKP 2 CMP INTAKE 3 CMP EXHAUST TRIGGER CYL1
Good Known

Type : Automotive
Oscilloscope : MT Pro 4
Rate : 200 kS/s
Samples : 13,382,880
File Size : 4.47 MB

Date : 2026-07-31

  • Visibility Public
  • Score 100
2008 VW Passat Wagon 2.0 TSI BPY Correlation known good

2008 VW Passat Wagon 2.0 TSI BPY Correlation known good

Cloud ID : 10358
Vehicle : Volkswagen Passat Wagon (2008)
Engine : Gasoline (2.0 L), 4 cylinders (1-3-4-2)
Engine Code : BPY
Note : TSI
Good Known

Type : Automotive
Oscilloscope : HS514
Rate : 75 kS/s
Samples : 2,961,094
File Size : 17.77 MB

Date : 2026-07-10

2011 GMC TERRAIN 2.4 CKP-CKP INT-CMP EXH-WPS500 BAR CYL4 AFTER REPAIRED

2011 GMC TERRAIN 2.4 CKP-CKP INT-CMP EXH-WPS500 BAR CYL4 AFTER REPAIRED

Cloud ID : 10274
Vehicle : GMC TERRAIN (2011)
Engine : Gasoline (2.4 L), 4 cylinders (1-3-4-2)
Engine Code : LAF
Note : 2011 GMC TERRAIN 2.4 AFTER TIMING CHAIN REPLACED 1 CKP 2 CMP INTAKE 3 CMP EXHAUST CH5 CYLL 4 TRIGGER CYL4
Good Known

Type : Automotive
Oscilloscope : MT Pro 4
Rate : 200 kS/s
Samples : 6,197,490
File Size : 93.32 MB

Date : 2026-06-08

  • Visibility Public
  • Score 112
2011 chevy silverado 5.3 power circuits with alternator test 4

2011 chevy silverado 5.3 power circuits with alternator test 4

Cloud ID : 10273
Vehicle : Chevrolet silverado (2011)
Engine : Gasoline (5.3 L), 8 cylinders (1-8-7-2-6-5-4-3)
Note : 2011 chevrlet silverado 1500 ch1 pinza de amperios ch2 voltaje de bateria ch3 voltaje de alternador ch4 amperaje del alternador
Good Known

Type : Automotive
Oscilloscope : MT Pro 4
Rate : 50 kS/s
Samples : 3,876,632
File Size : 10.87 MB

Date : 2026-06-08

  • Visibility Public
  • Score 102
2022 toyota c-hr new battery test

2022 toyota c-hr new battery test

Cloud ID : 10270
Vehicle : Toyota C-HR (2022)
Engine : Gasoline (2.0 L), 4 cylinders (1-3-4-2)
Note : New Battery
Good Known

Type : Automotive
Oscilloscope : MT Pro 4
Rate : 50 kS/s
Samples : 4,036,704
File Size : 1.85 MB

Date : 2026-06-07

  • Visibility Public
  • Score 100
« Previous 1 2 3 4 5 6 7 8 Next »
